窄巷道货架又称VNA货架，专指常规横梁式货架系统选用的叉车为三向叉车时的系统，其与常规托盘式货架系统相比，窄巷道托盘式货架系统的巷道宽度要比常规托盘式货架系统小的多，一般为1600-2000mm左右，空间利用率又提高了20%左右，在通道两侧必须设置导向护轨或安装地面磁感应，以为三向叉车行驶导向之用。
Very Narrow Aisle racking, also called VNA racking, refers to the storage system when three-direction forklift is used for common pallet racking system. Compared with common pallet racking, VNA racking has much narrower aisle (generally 1,600-2,000mm), so that the space utilization rate can be increased by 20% or so. In this system, guide rails or floor magnetic induction devices need to be installed on the two sides of channel to guide the direction of three-direction forklift.
.jpg)
叉车可在多巷道内灵活操作。
特殊VNA叉车可高速存取托盘。
窄巷道货架系统提供了一种安全及免损的存储环境。
必须考虑到消防和地震的特殊要求，耐磨和超平整的地面对重的静载和动载而言也是必须的。
托盘位使用率高达95%接近100%，地面使用率达50%，且有很高的空间利用率。
Forklift can be operated flexibly in several aisles.
Special VNA forklifts can quickly deposit and take out pallets.
VNA racking system provides a safe and damage-free storage environment.
Special requirements of fire protection and earthquake protection should be considered, and wearable and super flat floor is necessary for heavy static load or dynamic load.
The pallet location use rate is as high as 95% to 100%, the floor use rate is up to 50%, and the space use rate is very high.
